US Patent: 723,540
|
| Igniter Operating Mechanism for Explosive Engines
|
|
Patentee:
|
|
| Theodore C. Menges (exact or similar names) - Waterloo, Blackhawk County, IA |
| Manufacturer: |
| Not known to have been produced |
|
|
Patent Dates:
|
| Applied: |
Aug. 29, 1902 |
| Granted: |
Mar. 24, 1903 |
USPTO (New site tip)
Google Patents
Report data errors or omissions to steward
Joel Havens
"Vintage Machinery" entry for Cascaden-Vaughan Co.
|
|
Description: |
| Abstract:
The invention relates to operating mechanism for the electric igniters of explosive-engines, and seeks to provide a simple and effective construction which will be quiet and reliable in its operation.
Claim:
In an explosive-engine, the combination with a shifting electrode of a finger connected thereto, an igniter-operating lever for tripping said finger mounted intermediate its ends upon a fixed pivot, a longitudinal elongated slot in the outer end of said lever and an actuating-pin engaging said slot. |
|
